98-137261-F 41
Appendix A
Specifications A
SAILOR 6390 Navtex Receiver
Item Specification
Weight 1.3 kg
Dimensions L x W x H: 190 x 270 x 42.5 mm
Input voltage 12-24 VDC (10.8 VDC to 31.2 VDC)
Power consumption Typical 6.5 W
Heat dissipation <10 W
Temperature -15 °C to +55 °C (Operational)
-1C to +5C (Storage)
Compass Safe
Distance
20 cm (Standard magnetic compass)
20 cm (Emergency magnetic compass)
IP rating IP22 (estimated)
Navtex receivers 490 kHz, 518 kHz and 4209.5 kHz simultaneous reception.
Software updatable for 500 kHz NAVDAT
Antenna support Active and passive antenna (12 V @ 60 mA antenna supply)
Sensitivity
490/518 kHz
4209.5 kHz:
<12 dBV@10 /150 pF
<-6 dBV@50
<12 dBV@10 /150 pF
<6 dBV@50
