Page 18 Coby Electronics Corporation
English
Connections
Composite Video Out (Standard)
Using the supplied AV cable:
Connect one end of the yellow cable to the yellow Video Out jack of 1.
the unit.
Connect the other end of the yellow cable to the yellow Video In 2.
jack of a TV.
Press <V-MODE> on the remote until you see “CVBS” on the TV
screen to set the unit to the composite video mode.
The maximum output resolution for the composite video con-
nection is 480i.
Component Video Out (Good)
Using an optional component video cable:
Connect one end of the green, blue and red cables to the Y, Cb/Pb, 1.
and Cr/Pr Component Video Out jacks of the unit, respectively.
Connect the other end of the green, blue and red cables to the Y, 2.
Cb/Pb, and Cr/Pr Component Video In jacks of a TV, respectively.
HDMI Video Out (Best)
HDMI output presents the highest possible resolutions and video qual-
ity. If an HDMI input jack is present on your television, use it.
Connect one end of an HDMI cable (not supplied) to the HDMI 1.
output of the player.
Connect the other end of the HDMI cable to the HDMI input of your 2.
TV/monitor.
