Page 20 Coby Electronics Corporation
English
Connections
Speakers
This unit has an integrated amplier. Connect the supplied speakers to
enjoy your movies with .-channel surround sound!
If necessary, strip 3/8” (10 mm) of insulation from each end of the 1.
speaker wire.
While pressing the terminal levers of each speaker, insert the bare 2.
wire into the hole, then release the lever to secure the connection.
While pressing the speaker terminal levers of the unit, insert the bare 3.
wire into the hole, then release the lever to secure the connection.
The speaker wire and terminal for each speaker is color-coded for 4.
your convenience. The following table will help you match the
speakers to their proper terminal:
Terminal Speaker Color
SW Subwoofer Green
CEN Center Red
SR Surround Right Blue
SL Surround Left Yellow
FR Front Right Gray
FL Front Left White
Make sure that the terminals are connected to the bare wires
and not the insulation. Always match colored positive (+) termi-
nals together; and match black negative (-) terminals together. If
switched, the sound will be out of phase and will not be produced
correctly. Do not connect more than one wire to each speaker ter-
minal; do not connect one speaker to several terminals.
