Model Number HE150272
customercare@winplus.com.au
Product Overview
Printer Front View
1. X Rail
2. X Belt Drive
3. Extruder Spring Lever
4. Extruder Cooling Fan
5. X Stop (Micro Switch)
6. Filament Cooling Fan
7. Extruder Driving Motor
8. Filament Spool Holder
Assembly
9. Tower Frame
6
2
9
8
1
4 7
3
5
.
