BUC model and redundancy system numbers
112 Block Up Converter Systems 6700/6900 series User Guide
For example, the model number 6725-W/E-AC/EX-CE
represents a C-Band 25 W MBUC with waveguide output
using the Extended frequency band. It is AC powered via an
external power connector, and is CE-certified. It has no special
variants.
Frequency band Standard: 5.850 to 6.425 GHz for C-Band S
14.0 to 14.5 GHz for Ku-Band
Extended: 5.850 to 6.725 GHz for C-Band E
13.75 to 14.50 GHz for Ku-Band
Power supply 24 V DC 24
48 V DC 48
AC AC
Power connector IF N-type connector IF
External power connector EX
CE certification CE-certified CE
Not CE-certified Segment
omitted
Special variants Codes allocated as required
Table 27: Definition of the BUC model number (cont.)
Option Description Code
