Overview
10 Block Up Converter Systems 6700/6900 series User Guide
Figure 4: C-Band frequency conversion plan at an LO
frequency of 7375 MHz
Figure 5: C-Band frequency conversion plan at an LO
frequency of 7600 MHz
950 MHz
IF input RF output
525 MHz1 425 MHz6
850 MHz5
950 MHz
IF input RF output
750 MHz1 650 MHz6
850 MHz5
