BUC model and redundancy system numbers
114 Block Up Converter Systems 6700/6900 series User Guide
For example, the model number 6586-C/W-M2-TO represents
a C-Band transmit-only redundancy system using 60 W
MBUCs with waveguide output.
BUC model and
power group
LBUC C-Band: 5 W, 10 W, 20 W L1
Ku-Band: 4W, 8W, 16W
MBUC C-Band: 25 W, 40 W M1
Ku-Band: 16 W
C-Band: 60 W M2
Ku-Band: 25 W
HBUC C-Band: 120 W H1
Ku-Band: 40 W
System type Transmit-only (BUC) TO
Transmit/receive (BUC & LNB) TR
Table 28: Definition of the redundancy system number
(cont.)
Option Description Code
