Installation
NGT Transceiver Getting Started Guide 45
Figure 3: Typical mobile NGT AR or SR station
9350 ANTENNA
ANTENNA CONTROL
BATTERY
ANTENNA
HANDSET
CRADLE
HANDSET
SPEAKER
RF UNIT
CRADLE
BATTERY
ANTENNA CONTROL
ANTENNA COAXIAL
BATTERY
FUSE
RF UNIT
KEY
CIB
JUNCTION BOX
