Installation
NGT Transceiver Getting Started Guide 55
Figure 6: Typical fixed NGT AR Voice or VR station
BROADBAND ANTENNA
AC POWER
ANTENNA
ANTENNA CONTROL
6-WAY
CONNECTOR
10-WAY
CONNECTOR
OPTIONAL
TUNER
10-WAY
CONNECTOR
OPTIONAL
CONSOLE
SPEAKER
RF UNIT
POWER
SUPPLY
HANDSET
CRADLE
HANDSET
HANDSET & SPEAKER
CONNECTOR
