Inserting your battery into the radio
The battery is connected to the (J7) Connector located on the bottom of the radio and housed in a
latching battery compartment. The image below shows the placement and alignment of the
battery, battery compartment and radio.
CAUTION: To prevent damaging the 6110-MP and the battery, you must ensure that
the battery is correctly aligned to the battery connector (J7) on the 6110-MP before
attaching the latching battery compartment to the radio.
latch
battery
Sentry®-H
6110-MP
latching battery
compartment
battery connector (J7)
Charging and installing batteries
Page 4 Sentry-H 6110-MP Operator Guide
