Door Locks
1 BROWN/BLACK UNLOCK SWITCH ( 87A )
2 BLUE/BLACK UNLOCK MOTOR ( 30 )
3 VIOLET/BLACK UNLOCK POLARITY ( 87 )
4 WHITE/BLACK LOCK SWITCH ( 87A )
5 GREEN/BLACK LOCK MOTOR ( 30 )
6 VIOLET LOCK POLARITY ( 87 )
The door lock / unlock outputs are designed to control several dierent types of
systems which may require additional parts.
3 Wire Ground Switched Door Locks:
Connect the GREEN/BLACK wire to the wire that provides a ground signal from the
factory door lock switch to the factory door lock control relay.
Connect the BLUE/BLACK wire to the wire that provides a ground signal from the
factory door unlock switch to the factory door lock control relay.
Connect the VIOLET and the VIOLET/BLACK wires to a solid chassis ground point.
The WHITE/BLACK and BROWN/BLACK wires are not required for this type of door
lock/unlock system.
3 Wire Positive Switched Door Locks:
Connect the GREEN/BLACK wire to the wire that provides a +12 volt signal from the
factory door lock switch to the factory door lock control relay.
Connect the BLUE/BLACK wire to the wire that provides a +12 volt signal from the
factory door unlock switch to the factory door lock control relay.
Connect the VIOLET and the VIOLET/BLACK wires to a +12 volt battery source. The
WHITE/BLACK and BROWN/BLACK wires are not required for this type of door lock/
unlock system.
