Code Alarm PROFESSIONAL SERIES - Remote Control - Optional Features; Two Stage Door Unlock; Trunk Release and AUX Outputs

4
ca1155 rev B
10 Pin Input / Output Harness
12 Pin Main Harness
1
BROWNSIREN OUTPUT ( + )
2
RED BATTERY 12V ( + )
3
BLACKGROUND
4
BROWN/BLACKUNLOCK SWITCH ( 87A )
5
VIOLET/BLACK UNLOCK POLARITY ( 87 )
6
WHITE/BLACKLOCK SWITCH ( 87A )
7
GREEN/BLACK LOCK MOTOR ( 30 )
8
WHITE PARKING LIGHT OUTPUT
9
WHITE/RED PARKING LIGHT INPUT
10
WHITE PARKING LIGHT OUTPUT
11
VIOLET LOCK POLARITY ( 87 )
12
BLUE/BLACK UNLOCK MOTOR ( 30 )
12 PIN MAIN - POWER / LOCKS
1
PURPLE DOOR TRIGGER INPUT ( + )
2
GREEN/BLACK FACTORY DISARM OUTPUT ( - )
3
OPEN
4
GREEN DOOR TRIGGER INPUT ( - )
5
ORANGE GROUND WHEN ARMED OUTPUT ( - )
6
BROWN/BLACKHORN OUTPUT ( - )
7
VIOLET/BLACK AUX 1 ( - )
8
GRAY HOOD PIN INPUT ( - )
9
YELLOWIGNITION INPUT ( + )
10
RED/WHITETRUNK RELEASE OUTPUT ( - )
10 PIN INPUT / OUTPUT
