Code Alarm PROFESSIONAL SERIES - 2-Way Remote Control Feedback; 2-Way Remote Control Responses

8
ca1155 rev B
10 Pin Input / Output Harness
1 PURPLE DOOR TRIGGER INPUT ( + )
Locate the vehicle’s dome light or door pin switch wire.
 Verication:This wire will register positive voltage (POS) when the door is
opened and the interior light is on. This wire will
register ground or “0” Volts when the door is closed and the interior light is
o󰀨.
Connect the PURPLE wire to the vehicle’s positive door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide
4 GREEN DOOR TRIGGER INPUT ( - )
Locate the vehicle’s dome light or door pin switch wire.
 Verication:This wire will register ground (NEG) when the door is opened
and the interior light is on. This wire will register positive voltage when the
door is closed and the interior light is o󰀨.
Connect the GREEN wire to the vehicle’s negative door input wire(s).
NOTE: Certain vehicles may require multiple connections. Refer to vehicle
application guide
2 GREEN/BLACK FACTORY DISARM ( - )
This wire will supply a ( - ) 300mA pulse both upon disarming the system and when
the trunk release feature is activated. Locate the factory perimeter alarm disarm wire
from the key cylinder inside the drivers door.
  Verication: This wire registers ground if the key is turned to the unlock
position in the driver’s door cylinder.
Connect the GREEN/BLACK wire to the factory alarm disarm wire.
3 OPEN
