6
ca1155 rev B
8 WHITE PARKING LIGHT OUTPUT
9 WHITE/RED PARKING LIGHT INPUT
10 WHITE PARKING LIGHT OUTPUT
Locate the parking light output wire at the vehicle’s light switch.
Verication: This wire registers positive voltage when the parking lights
are turned on.
Positive switching Parking Lights:
Connect the WHITE/RED wire to a 15 Amp max fused battery source.
Connect the WHITE wire to the parking light output wire.
Negative switching Parking Lights:
Connect the WHITE/RED wire to a good chassis ground.
Connect the WHITE wire to the parking light output wire.
4 BROWN/BLACK UNLOCK SWITCH ( 87A )
Refer to the Door Lock Section on page 11 of this guide.
5 VIOLET/BLACK UNLOCK POLARITY ( 87 )
Refer to the Door Lock Section on page 11 of this guide.
6 WHITE/BLACK LOCK SWITCH ( 87A )
Refer to the Door Lock Section on page 11 of this guide.
7 GREEN/BLACK LOCK MOTOR ( 30 )
Refer to the Door Lock Section on page 11 of this guide.
