CB 2 Series
Administrator Guide
Tools needed for installation:
1. Drill
2. Drill bit (5/8” Masonry bit for concrete; 1/2” standard bit for wood)
3. 3/8” Hex head driver bit
4. Level
Basic installation instructions:
1. Unscrew security screw from bottom of unit. Lift and open unit.
2. Disconnect wire connections from strobe, faceplate light and phone. Lift up on black locking
tab on each connector to separate.
3. Unscrew the nut from the stud to release safety cable from back plate. Place nut back on
stud.
4. Lift up on front of unit and remove. Set aside.
5. Using back plate of unit as template, level and mark the four mounting holes.
6. Drill all marked holes with appropriate drill bit.
7. If attaching to concrete or brick, insert one 3/8” anchor into each drilled hole.
8. If attaching to wood, 3/8” lag bolt is required.
9. On one 3/8x3” lag bolt, add one 3/8” at stainless steel washer followed by one 3/8” at rub-
ber washer.
10. Slide lag bolt through top left mounting hole.
11. Add one 3/8” at rubber washer, followed by one 3/8” at stainless steel washer to end of
screw.
12. Drill lag bolt into mounting hole.
13. Repeat previous steps for three remaining mounting holes.
14. Slide front of unit back onto bottom tabs of back plate.
15. Reattach safety cable.
16. Reconnect strobe, faceplate light and phone to power system.
17. Connect incoming power to appropriate tap (high voltage or low voltage).
18. Connect incoming communication line (CAT6) to phone using its WAN port.
19. Close unit.
20. Replace security screw into bottom of unit.
