CB 2 Series
Administrator Guide
33 CB 2 Series 120V Standard Wiring
(prior to 03/2013)
(with Hammond Transformer)
(with Hammond Transformer)
Product wiring diagram shown reasonably represents current offering and is intended to assist in component identi cation and service. Earlier product
production may have different components and wiring connections. Reference the model and serial number from the unit ID tag and contact
manufacturer to con rm replacement part version and availability.
