Command
Explanation
Format
Default
31
Button 1 (Red)
31<phone number>*<output(s)>*<recording(s)>#
123*13*1#
32
Button 2 (Black)
32<phone number>*<output(s)>*<recording(s)>#
0456*2*#
33
Button 3
33<phone number>*<output(s)>*<recording(s)>#
**#
34
Button 4
34<phone number>*<output(s)>*<recording(s)>#
**#
35
Input 1
35<button>#
0#
36
Input 2
36<button>#
0#
37
Loss of AC Power
37<phone number>*<output(s)>*<recording(s)>#
7**7#
38
Low Battery
38<phone number>*<output(s)>*<recording(s)>#
8**8#
39
PAS Fault
39<phone number>*<output(s)>*<recording(s)>#
9**9#
page 27 of 45 GU-139-Z1
(Continued on next page)
Programming Commands (continued)
Programming Buttons and Inputs
NOTES:
For Programming Phone Numbers, see Commands 01 to 09 (page 20).
If the first phone number slot entered is zero and a keypad (i.e., FP2-K faceplate) is
connected, then this button (other than RED) will activate as manual call mode. Or if
entering a number slot (e.g., 31123**# or 32456**#) has a phone number programmed
and a keypad is present, the number will be auto dialed. Upon the call being
detected and answered by voice message (auto attendant), the user is allowed keypad
access to dial a number allowed by system.
For setting outputs 1 through 3 on, see Programming Outputs, Commands 11 to 13
(page 26).
For recorded messages, see Programming Recordings 1 through 9, see Commands 21
to 29 (page 26).
A message will play over the speaker immediately after a button press in the order in
which they were programmed.
For Input Commands 35 and 36, the input associated with the button is as follows:
0 = disabled
1 to 4 = button 1 to 4
Voltage controlled relays = 9-32 volts AC or DC
