page 29 of 45 GU-139-Z1
40
41
42
43
44
45
46
47
Polarity Reversal/WINK
Revert back to dial tone
Silent time out
Repeating (reorder) tone
Call time out
WINK Voltage Minimum
Minimum Ring Voltage
Detection
Maximum Ring
Frequency
40<Polarity Reversal/WINK time>#
41<length of dial tone>#
42<silence time>#
43<number of reorder tones>#
44<call time># (30-second notifier)
45<Voltage>#
46<0, 1 or 2>#
47<0, 1 or 2>#
2#
00#
0#
00#
10#
0#
0#
0#
(Continued on next page)
Programming Hang Up Methods
Command Explanation Format Default
NOTES: FORMAT VALUE PARAMETERS
Command 40 = WINK time: 0 - 9
0 = disabled
1 - 9 = 100 - 900 milliseconds
Command 41 = Length of dial tone: 00 - 99
00 = disabled
01 - 99 = 1 - 99 seconds
Continuous sound for this period will initiate hang up
Command 42 = Silent time out: 0 - 9
0 = disabled
1 to 9 (10 to 90 in 10-second increments)
Command 43 = Number of repeating tones: 00 - 99
00 = disabled
01 - 99 = 1 - 99 cycles
Command 44 = Call time out timer: 00 - 99
00 = disabled
01 - 99 = minutes
A DTMF “BBBBB” notifier plays to both parties 30 seconds prior to expiration
Command 45 = Minimum “voltage change” to interpret as a “WINK”
0 = 5V thru 9 = 14V
Command 46 = Minimum Ring Voltage Detection Threshold measured in Vrms
0 = 13, 1 = 19
2 = 40
Command 47 = Maximum Ring Frequency measured in Hz
0 = 75, 1 = 50, 2 = 35
IA4100
Administrator Guide
Code Blue
• 259 Hedcor Street • Holland, MI 49423 USA • 800.205.7186 • www.codeblue.com
Programming Commands (continued)
