Programming Call Properties
NOTES: FORMAT VALUE PARAMETERS
Command 50 = Give up wait for dial tone: 00 -99
00 = ring down
01 - 99 = 1 - 99 seconds
If dial tone is not detected in this time, the phone will hang up (default is 5 seconds).
Command 51 = Call progress detection delay: 1 - 99
1 - 99 = 1 - 99 seconds
Call progress tone detection. Time that the phone will wait monitoring progress tones.
Command 52 = Wait for answer: 00 - 99
00 - 99 = 0 - 99 seconds
Time that the phone will wait from initiation for a call to be answered before dialing the next number
Command 53 = Call connected detection: 0 or 1
0 = When voice or DTMF is detected by the IA4100
1 = After call is placed (non-ADA; forces call to connect)
Command 54 = Call Loop Cycle: 1- 9
1 - 9 = 1 - 9 loops
The number of dialing attempts the phone will perform on all programmed phone numbers, in order,
before resetting to standby
Command 55 = Force half duplex operation: 0 or 1
0 = full duplex
1 = half duplex
Command 56 = Full duplex noise cancellation: 0 - 3
0 - 3 = low to high
Command 57 = Local loop training
Train and tune to the local loop length
Command 58 = Answer message repeat playing: 0 or 1
0 = message is played once upon call answered
1 = message is played continuously until DTMF 33 is pressed by guard
See Programming Buttons and Inputs, Commands 71 - 74 (page 27)
Command 59 = RFA tone delay: 00 - 99
00 - 99 = 0 - 1980 milliseconds
The amount of delay when the IA4100 answers and plays the RFA tone
The delay “value” is multiplied by 20 milliseconds. For example, the default value “15”
equals 300 milliseconds (15 x 20 = 300) or a “value” of 99 equals 1,980 milliseconds (99 x 20 =
1980).
Command Explanation Format Default
50
51
52
53
54
55
56
57
58
59
Give up waiting for dial tone
Call progress detection delay
(give up time waiting after dial)
Give up time waiting for answer
Call connected detection
Call loop cycles
Force half duplex operation
Full duplex noise cancellation setting
Local loop training
Answer message repeat playing
Request for Acknowledgement beep delay
50<time>#
51<time>#
52<time>#
53<mode>#
54<cycles>#
55<full/half duplex>#
56<noise setting>#
57#
58<message repeat>#
59<delay>#
5#
20#
30#
0#
2#
0#
0#
#
0#
15#
