Code Reader 1000 User Manual
4
of 1
of 1 rating
13 pages
Give review
Manual
Specs
To Next Page
To Next Page
To Previous Page
To Previous Page
Loading...
C005905_04_CR1000_User_Manual
12.0 - CR1000 Hole Mounng P
aern
13.0 - CR1000 Over
all Dimensions
NOTE 1:
LOCA
TING HOLES ARE 2MM IN DIAMETER, HOLE DEPTH is 1.5 MM
NOTE 2:
MOUNTING INSERTS ARE M3-.5 INTERNAL THREAD
, 3.8MM LENGTH
6
9
11
Table of Contents
Statement of Agency Compliance
2
Table of Contents
4
Unpacking
5
Attaching/Detaching a Cable
5
Powering the Reader On/Off
5
Using a CR1000 out of a Stand
6
Using a CR1000 in a Stand
6
Reading Range
7
Reader Feedback
7
Symbologies Defaulted on
8
Symbologies Defaulted off
8
Locating the Hardware Revision Number
8
Reader ID & Firmware Version
9
Hole Mounting Pattern
10
CR1000 Overall Dimensions
10
USB Cable Example with Pinouts
11
RS232 Cable Example with Pinouts
11
Reader Pinouts
12
Maintenance
12
Note
13
Warranty
13
