Code Reader 1000 User Manual

C005905_04_CR1000_User_Manual
6.0 - Reading Ranges
Note: working ranges are a combinaon of both the wide and high density elds. All samples were high quality codes
and were read along a physical center line at a 10° angle. Default AGC sengs were used. Accuracy= +/- 10%.
3
7.0 - Reader Feedback
Scenario Top LED Light Sound
CR1000 Successfully
Powers Up
Green LED Flashes 1 Beep
CR1000 Successfully
Enumerates with Host
(via cable)
Once Enumerated,
the Green LED turns O
1 Beep
Aempng to Decode Green LED Light is O None
Successful Decode and
Data Transfer via Cable
Green LED Flashes 1 Beep
Conguraon Code Successfully
Decoded and Processed
Green LED Flashes 2 Beep
Conguraon Code successfully
decoded but wasn’t
successfully processed
Green LED Flashes 4 Beeps
CR1000 Performance
Test Code Min Inches (mm) Max Inches (mm)
3 mil Code 39 3.1” (80 mm) 4.0” (102 mm)
7.5 mil Code 39 1.3” (33 mm) 7.2” (182 mm)
10.5 mil GS1 DataBar 0.8” (20 mm) 8.7” (220 mm)
13 mil UPC 1.1”(28 mm) 11.0” (280 mm)
4.2 mil Data Matrix 1.9” (48 mm) 4.3” (110 mm)
5 mil Data Matrix 1.7” (43 mm) 4.5” (115 mm)
6.3 mil Data Matrix 1.3” (33 mm) 5.9” (150 mm)
10 mil Data Matrix 0.8” (20 mm) 7.1” (180 mm)
20.8 mil Data Matrix 1.1” (28 mm) 13.5” (343 mm)

Code Reader 1000 Specifications

General

Brand	Code
Model	Reader 1000
Category	Barcode Reader
Language	English
