Operation and Maintenance Manual

Issue : A Rev. : 3 Date : 13/11/2018 Ref. : 100351

P a g e | 13

4.2.1 Power Connection:

Place 24V screened cable through the gland and connect to CON1 24V power input as described below.

Figure 6: Power Connection

4.2.2 RS485 Connection

Figure 7: RS485 Connection

0V 24V
