Cognex AS200 - Adjust Region; Adjust Focus

Adjust Region
1.
To adjust the auto image brightness region, click to enter the interactive
graphics mode.
2. Position the region around the image area that the camera will use to
determine the automatic exposure settings. Ideally, this region should
contain all features you want to locate during run time.
3.
To accept the region and exit the interactive graphics mode, click on the
right top corner of the screen.
Tip: To accept the region and exit the interactive graphics mode, you
also can double-click on the region.
Adjust Focus
1. To enter the Live Video mode, which enables you to adjust the lens focus,
click above the image display.
2. Adjust the focus of the lens to ensure that the feature details are clear and
highly contrasted.
3.
When you are satisfied with the quality of your image, click again to exit
the Live Video mode.
28
