Reader Layout
DM280 EtherCAT Layout
The image and table below show the elements of the reader.
Number Description
1 Power I/O Breakout cable connector
2 USB-C slot (with plastic cover)
3 Network connector (EtherCAT)
4 Ethernet connector
