Connecting the Ethernet Cable
CAUTION: The Ethernet cable shield has to be grounded at the far end.
Whatever this cable is plugged into (typically a switch or router) should have a
grounded Ethernet connector. A digital voltmeter has to be used to validate
the grounding. If the far end device is not grounded, a ground wire should be
added in compliance with local electrical codes.
1. Connect the Ethernet cable's M12 connector to the reader ENET
connector.
2. Connect the Ethernet cable’s RJ-45 connector to a switch/router or PC, as
applicable.
Note:
Besides powering the DataMan 280 readers through a Breakout
Cable, it is possible to power DataMan through PoE connection as
well, in which case it is not necessary to use a Breakout Cable.
