Number Description
12 Indicator LEDs
13 Power LED indicator
14 Train status/Trigger status LED indicator
15 Good/bad read LED indicator
16 Communication LED indicator
17 Error LED indicator
1
For more information on the EtherCAT LEDs, see EtherCAT Indicators on page18.
17
