Working distance in mm Horizontal values in mm
Vertical values in mm
Z
3
= 375 X
3
= 116 Y
3
= 87
Z
4
= 1000 X
4
= 310 Y
4
= 232
Distances in mm 2D min. code in mil 1D min. code in mil
80 2 2
150 3 2
190 4 3
225 5 3
375 8 5
500 10 7
1000 20 15
27
