Specification
DataMan 280 EC
Humidity <95% non-condensing
Environmental
IP67
Note: IP67 rating applies only if all blind plugs and cables are attached properly, or
the provided connector plug is installed. Also, make sure that the IP67-rated cover is
installed properly.
Shock
IEC 60068-2-27 - 500 shocks in each polarity of each (X, Y, and Z) axis, 3000 shocks total,
semi-sinusoidal, 11 g, 10 ms
Shock
(Shipping and
Storage)
ISTA-1A Standardized Testing - Packaged Products 150 lb or less
Vibration IEC 60068-2-6: vibration test in each of the three main axis for 2 hours @ 10 Gs (10 to 500
Hz at 100m/s
2
/ 15 mm)
Vibration
(Shipping and
Storage)
FedEx Vibration Testing for packaged products 150 lbs or less
Codes
1-D barcodes: Codabar, Code 39, Code 128, Code 93, Code 25, Interleaved 2 of 5, Postal
Codes, UPC/EAN/JAN, MSI
2-D barcodes: Data Matrix (IDMax and IDQuick: ECC 0, 50, 80, 100, 140, and 200), QR
Code, microQR, PDF 417, AztecCode, DotCode, MaxiCode
EtherCAT
For details on the EtherCAT interface, see Connecting the EtherCAT Cable to the DataMan
280 EtherCAT Reader on page31.
37
