Cold Jet PR120H - Procedure for Changing Gaskets in Hydraulic Cylinders on Pr120 H

PR120H
MECHANICAL MAINTENANCE
Version: 5
Page: 8 of 24
Date: 2022.12.13
4. PROCEDURE FOR CHANGING GASKETS IN HYDRAULIC CYLINDERS ON PR120H
During this operation it’s important to activate the emergency stop button!
Important!
For operators safety the hydraulic cylinder has to be disconnected from the hydraulic system before dismounting.
1. Piston 4. Piston rod
3. Cylinder tube 2. Cylinder top
