Cold Jet PR120H - Page 98

Tag-numbers for IceMaker PR120H
P294-1-11991-G
CE/UL 3x400V AC 50 HZ/3x480V AC 60 Hz.
7/9/2020
ASPECT ASPECT DESCRIPTION TAG TAG DESCRIPTION
IceTech
Varenummer
Beskrivelse Datablad relative links
DIPR120H Dry Ice Production Unit I O I O
DIPR120H=V01 Armstrong Kit Option
DIPR120H=V01 Filter unit -Q2 Valve for degassing filter unit 101099 032F101 00 EVR 15
DIPR120H=V01 Filter unit -Q2-K1 Solenoid for valve, filter unit 103005-1 018F6857 24 V DC
DIPR120H=V01 Filter unit -QL1 Float valve for filter unit 100067
1 datablade\ICPD600A202.indd.pdf
DIPR120H=W01 Pipe system
DIPR120H=W01 Pipe system -Q1 Valve 1 for inlet 502415 Ball valve single acting pneu. actuator
DIPR120H=W01 Pipe system -Q1-KA1 Solenoid for valve 1, inlet 502415 Solenoid 24 V DC
DIPR120H=W01 Pipe system -QF1 Safety valve 1 for pipe system 101221 27,6 bar
DIPR120H=W01 Pipe system -QF2 Safety valve 3 for pipe system 101223 1 bar
DIPR120H=W01 Pipe system -TT1 Temperatur transmitter T1 for liquid 103024 TSPT100A 1
DIPR120H=W01 Pipe system -TP1 Pressure transmitter P1 for liquid 500408 Endress+Hauser 0-40bar 4-20mA ud PMP131-A4401A1X
DIPR120H=W01 Pipe system -V1 Filter for CO2 liquid
DIPR120H=W01 Pipe system -Q2 Check Valve CO2 out 512853 VALVE, CHECK, 1 1/ 2 IN, BSPP PT100 datablade\Sensonic_LTT-TS-TSPT.pdf
DIPR120H=W01 Pipe system -E1 Heat Exchanger 510892 Mechanical Part, SWEP B12MTx30/1P-SC-S
4-20mA datablade\PMP131.pdf
DIPR120H=G01 Extruder for dry ice pellets
DIPR120H=G01 Extruder for dry ice pellets -Q1 Valve 1 for pellet extruder 502456 30° V-ball valve single acting pneu. actuator
DIPR120H=G01 Extruder for dry ice pellets -Q1-KA1 Solenoid 1 for pellet extruder valve 1 502456 Solenoid 24 V DC
DIPR120H=G01 Extruder for dry ice pellets -Q1-BG1 Position switch for valve 1 closed 502456 Induktiv endestop
DIPR120H=G01 Extruder for dry ice pellets -Q2 Valve for degassing filter unit 502456 30° V-ball valve single acting pneu. actuator
DIPR120H=G01 Extruder for dry ice pellets -Q2-KA1 Solenoid 1 for valve, filter unit 502456 Solenoid 24 V DC 1
DIPR120H=G01 Extruder for dry ice pellets -Q5 Valve for degassing filter unit 101099 032F101 00 EVR 15 1
DIPR120H=G01 Extruder for dry ice pellets -Q5-K1 Solenoid for valve, filter unit 103005-1 018F6857 24 V DC
DIPR120H=G01 Extruder for dry ice pellets -TP1 Pressure transmitter 1 for pellet extruder 500260 Endress+Hauser 0-4bar 4-20mA ud PMP131-A4401A1Q 1 datablade\ICPD600A202.indd.pdf
DIPR120H=G01 Extruder for dry ice pellets -PP1 Manometer for pellet extruder 500247 0-10 Bar
DIPR120H=G01 Extruder for dry ice pellets -G1 Extruder for dry ice pellets 1 datablade\ICPD600A202.indd.pdf
DIPR120H=G01 Extruder for dry ice pellets -G1-MO1 Hydraulic cylinder for pellet extruder 4-20mA datablade\PMP131.pdf
DIPR120H=G01 Extruder for dry ice pellets -G1-TG1 Position transmitter 1 for pellet extruder Balluff BTL7-V50E-M0???-A/B/Y/Z(8)-C003 EtherCAT
DIPR120H=HU01 Hydraulic unit for pellet extruder
DIPR120H=HU01 Hydraulic unit for pellet extruder -C1 Tank for hydraulic unit EtherCAT Datablade\BA%20BTL7-V50E-M%20%20%20-ABYZ(8)-C003_910168_F14_EN.pdf
DIPR120H=HU01 Hydraulic unit for pellet extruder -C1-V1 Refill filter for hydraulic tank
DIPR120H=HU01 Hydraulic unit for pellet extruder -C1-BL1 Level switch for hydraulic tank Niveau- og temperaturvagt HMFB-OT 0=200 T=70gr.C
DIPR120H=HU01 Hydraulic unit for pellet extruder -C1-PL1 Sight glass level for hydraulic tank
DIPR120H=HU01 Hydraulic unit for pellet extruder -G1 Pump for hydraulic unit PLP20.11,2D Polaris
DIPR120H=HU01 Hydraulic unit for pellet extruder -G1-M1 Motor for hydraulic pump 5,5 kW motor 3x230/400V-50Hz 1400 omdr/min 1
DIPR120H=HU01 Hydraulic unit for pellet extruder -PP1 Manometer for hydraulic unit
DIPR120H=HU01 Hydraulic unit for pellet extruder -Q1 Valve for hydraulic unit 1 Atos (Hydragrene)DKE-1610-X24-DC
DIPR120H=HU01 Hydraulic unit for pellet extruder -Q1-K1 Solenoid for hydraulic valve 1 Atos (Hydragrene)DKE-1610-X24-DC Se datablad
DIPR120H=HU01 Hydraulic unit for pellet extruder -Q2 Valve for hydraulic unit 2 Atos (Hydragrene)DKE-1711-X24-DC
DIPR120H=HU01 Hydraulic unit for pellet extruder -Q2-K1 Solenoid 1 for hydraulic valve 2 Atos (Hydragrene)DKE-1711-X24-DC Datablade\DKE1610-H%20OG%20DKE1711-H.pdf
DIPR120H=HU01 Hydraulic unit for pellet extruder -Q2-K2 Solenoid 2 for hydraulic valve 2 Atos (Hydragrene)DKE-1711-X24-DC 1 datablade\DKE1610-H OG DKE1711-H.pdf
DIPR120H=HU01 Hydraulic unit for pellet extruder -QP1 Pressure valve for hydraulic unit
DIPR120H=HU01 Hydraulic unit for pellet extruder -TT1 Temperature transmitter for hydraulic unit 103024 TSPT100A 1 datablade\DKE1610-H OG DKE1711-H.pdf
DIPR120H=HU01 Hydraulic unit for pellet extruder -TP1 Pressure transmitter for hydraulic unit
500261
Endress+Hauser 0-200bar 4-20 mA 1 datablade\DKE1610-H OG DKE1711-H.pdf
DIPR120H=HU01 Hydraulic unit for pellet extruder -V2 Filter for hydraulic unit
DIPR120H=HU01 Hydraulic unit for pellet extruder -X1 Distribution block for hydraulic unit PT100 Datablade\Sensonic_LTT-TS-TSPT.pdf
4-20mA Datablade\PMP131.pdf
DIPR120H=V02 Ice Cutter KIT
DIPR120H=V02 Ice Cutter KIT -BL1 Level switch for handling unit 500518 Kapacitativ føler - lav temperatur
DIPR120H=V02 Ice Cutter KIT -V1-M1 Motor for dry ice cutter 513704 Gearmotor, SSN31-1UHAR, 180W, 457 rpm 480/400 Volt
Digital I/O
Analog I/O
P294-1-11991.xlsx
Side 1 af 1
