PR120H
User’s manual
Version: 1
Page: 3 of 14
Date: 2023.01.19
TECHNICAL DATA - SAFETY REGULATIONS
Rated Output:
Kg/h: up to 120 / lbs/h: up to 265
Of high quality dry ice pellets, depending on the extruder plate applied
Pellet Size:
Diameter:
Mm: 3 - 10 or 16 / Inch: 1/8 – 3/8 or 5/8
Cylindrical - length varying from:
Mm: 50 to 100 / inch: 2 to 4
Inlet Liquid CO2 Pressure:
Bar: 16 – 22 / Psi: 232 – 319
Liquid CO2 Dryness Fraction:
The water content should not exceed 35 ppm and should not be less than 5 ppm – or equivalent to a dewpoint
Temperature of -66°C to -51°C (-86.8°F to -59.8°F).
NOTE:
The liquid CO2 supply must be completely free of oil and must have a purity of minimum 99.9%.
Liquid CO2 Supply Pipe:
Internal dia. 20 mm (3/4 inch), very well insulated with a minimum number of bends and fittings.
NOTE: If over 20 m (65.6 feet) in length, always use an internal dia. of 25 mm (1 inch).
Compressed air / CO2 gas pressure:
Bar: 8 – 10 / psi: 116 – 145
Air quality Class 3 – according to ISO 8573-1
Power Supply:
3 x 400 V AC + PE, 50Hz,
TN-S Earthing system
Imax. 16 A
480V AC Solidly Grounded Wye Source
3 Phase + GND wire, 60Hz
Imax. 16 A
Control Panel SCCR: 25kA rms symmetrical 480VAC Max.
Rated power:
8,3 kW / 10,7 Hp
Machine Dimensions:
Length: 1150 mm / 45,3 in
Width: 650 mm / 25,6 in
Height: 1738 mm / 68,4 in
Weight: 754 kg / 1662 lbs
Noise level: below 75 dB(a)
