Coldelite UC 511 G - Parts Identification

29
1750250
1745210
PARTS IDENTIFICATION
Code No. Description Code No. Description
1903290* Right side panel 1750250 Mix tank cover
1722620 Touch panel 1746020* Spring
1904390* Rear panel 1746010* Cover: rear drip tray
1902300 Left side panel 1906350 Front panel
1745210 Plastic drip chute 1720710 Proximity switch
1745651 Tray
1746020
1746010
*Not pictured
Figure D
Figure A
1720710
1902300
1904390
1722620
1903290
1906350
1745651
