Collamat 3600 - Page 8

How to connect a goods scanner
The goods scanners and incremental encoders are connected to the GSC1 and GSC2
connectors. Figure 3 shows the connection of the standard Collamat Stralfors AG
IR goods scanner:
Figure 3: Connection of the CS IR goods scanner
Figure 4 shows the connection of a NPN-scanner:
Figure 4: Connection of a NPN-scanner
IR
wht GSC1
yel
GSC2
brn GND
grn +12 V
brn GND
grn
+12 V
GND
GSC1
+12V
GND
LSC
TCY
+12V
GND
+12V
NPN
GSC1
GND
+12 V
GND
GSC1
+12V
GND
LSC
TCY
+12V
GND
+12V
5999.527-01A 25.11.98 WM Seite 7 / 32
