6. LCD Operation Instruction
6.1 Operational Motion Instruction
Knob/OK:
➢ Press the knob/OK under main interface to enter operation interface of menu;
➢ Rotate the knob to select menu or press the knob/OK under the operation interface
of menu to select current menu or enter submenu;
➢ Rotate the knob to adjust parameters after selecting the menu with parameter; and
it will be auto saved within one second after adjustment.
ESC: Return key, exit current menu or operation.
6.2 Main Interface
After starting X4, main interface of LCD display is as follows:
First row: Company name.
Second row: Image resolution.
Third row: Screen brightness, Image signal resource.
6.3 Operation Instruction
Press the knob/OK to enter the operation interface of main menu, and it includes 8
operation instructions: Display Setting, EDID Setting, Input Setting, Input Clip Setting,
Output Setting, Output Shift, Language Setting, System Setting.
