Colorlight X4 - Output Interface Ports; Controlling Interface Ports

www.colorlightinside.com
3
6
AUDIO
Audio input, input audio signal and transmit to the
multifunction card
Output Interface
1
Port1/2/3/4
RJ45，4 Gigabit Ethernet outputs
Controlling Interface
1
USB_OUT
USB output, cascading with next controller
2
USB_IN
USB input, which connects with PC to configure parameters
