• 115200
• 128000
• 230400
• 1M
• 2M
3.8 AutoCal Speed
This option is used to perform an automatic belt speed and odometer distance calibration. You must have the
Speed Sensor to successfully perform this function.
Press the ODOMETER RESET button to select the option. The screen will display: Run to Start…
Press the MODE button to toggle the treadmill belt mode from STOP to RUN. The treadmill belt will move at
half-speed and a 15-minute timer will begin to count down: Stop to Cancel… Waiting: 14.59s
The automatic calibration procedure can be stopped at any time by pressing the MODE button to toggle the
treadmill belt mode back to STOP.
Now the Speed Sensor needs to be installed on the Treadmill and Connected to the Treadmill Controller.
• Remove the thumbnuts, treadmill cover, and lid.
• Place the Speed Sensor over one of the threaded studs and secure with a thumbnut. Be sure the wheel
is aligned parallel to the running belt.
After the count down time expires, the Treadmill Controller will check for a speed output from the Speed
Sensor. If detected, then the calibration procedure will continue, if not detected, then the screen will display:
Speed Sensor Not Detected… Verify the connection to the treadmill, if all appears correct try cycling the
AC power and start the calibration again. If that doesn’t work, contact Columbus Instruments for help. Once a
speed output has been detected, the low-speed calibration will automatically begin.
The Treadmill Controller will calibrate the low speed of 10.0 meters/minute and then the high speed of 100.0
meters/minute (each within the span of 3 minutes and 17 seconds). Lastly it will calibrate the odometer
distance in one minute and then display the measured counts from the motor odometer. Press the
ODOMETER RESET button to save the new calibration settings. Then the screen will display: Stop to
Finish… Press the MODE button to toggle the belt mode back to STOP and return to the User Menu.
3.9 Acceleration Settings
This option is used to set the acceleration rate and end speed of the treadmill belt when the treadmill belt
mode is set to ACCELERATION. The screen displays the acceleration units and three adjustable settings:
