Columbus Instruments Exer 3/6 Hardware Manual

43
Treadmill Hardware Manual 1011-0002 v1.02
• Insert appropriate stimulus boxes and front cap.
7.2.2 Setting Angle of Inclination
The angle of inclination can be increased by moving the support bar to the next slot. The slots range from
-10°-25°, in 5° increments.
7.3 Connecting Components
• Make sure that the power switch, which is on the controller on the rear panel above the power cable
connector, is in the OFF position.
• Locate the black round-type motor cable and the black shielded shocker ribbon cable(s).

Columbus Instruments Exer 3/6 Specifications

General

Brand	Columbus Instruments
Model	Exer 3/6
Category	Treadmill
Language	English
