Angle of Inclination: -10°‐25° in 5° increments
Maximum Shock Voltage: 163V, 200ms pulse
Maximum Shocker Current: 0.34‐1.6mA
Enclosure Dimensions ‐ Rats: 546 x 139 x 203mm (21.5 x 5.5 x 8in)
Enclosure Dimensions ‐ Mice: 384 x 51 x 102mm (15.1 x 2 x 4in)
Running Surface Dimensions ‐ Rats: 381 x 139 x 127mm (15 x 5.5 x 5in)
Running Surface Dimensions ‐ Mice: 305 x 51 x 44mm (12 x 2 x 1.75in)
Shocker Grid Dimensions ‐ Rats: 139 x 89mm (5.5 x 3.5in)
Shocker Grid Dimensions ‐ Mice: 139 x 51mm (2 x 2in)
6.1.1 Treadmill Controller
Power Requirements: 200 watts, 100, 115, or 230VAC, 50/60Hz (factory selected)
Physical Dimensions: 36.8 x 30.5 x 10.9cm (14.5 x 12.0 x 4.3in)
Physical Weight: 4.8kg (10.6lb)
User Controls: 3 x Push-Button Rotary Encoders
Speed Sensor Connection: 6.35mm (1/4in) Female Stereo Phone Jack
Fan Connections: 3.50mm (1/8in) Female Mono Phone Jack (x4)
CI-Bus Connections: 8p8c (RJ45 Ethernet) Modular Jack (x2)
Shocker Connection: 15-pin Female D-SUB
Motor Connection: 6-position Molex 5566 Mini-Fit Jr Male Header
Belt Speed Range: 0.0 – 102.3 meters/minute
Acceleration Range: 0.0004 -25.5 meters/minute/second
Time Limited Range: 0:00:01s to 4:15:59s
Distance Limited Range: 1.0 to 9,999.0 meters
6.1.2 Optional Electric Stimulus
Mouse Grid Dimensions: 0.3 x 11.4cm rods, 1.0cm apart, 5 - 6 rods typical
(0.1” x 4.5” rods, 0.4” apart, 5 - 6 rods typical)
Rat Grid Dimensions: 0.3 x 11.4cm rods, 1.0cm apart, 11 rods typical
(0.1” x 4.5” rods, 0.4” apart, 11 rods typical)
Stimulus Voltage: 117VAC 50/60Hz
Stimulus Current: up to 2.34mA
Stimulus Durations: 200mS
Stimulus Repetition Rate: 1, 2, or 3Hz
Stimulus Control: 2-position toggle switch (on/off) for each lane
The INTENSITY adjusts the maximum current for each lane
6.1.3 Optional Air-Puff Stimulus
Stimulus Pressure: 0-2069mmHg (0-40PSI), 19-liter (5-gallon) reservoir typical
Stimulus Nozzles: Six per Mouse Lane, Ø 1.4mm x 13.9mm (Ø 0.055in x 0.545in)
Stimulus Duration: 200mS
Stimulus Repetition Rate: 1, 2, or 3Hz
