1.1.2 Optional Air-Puff Stimulus
Stimulus Pressure: 0-2069mmHg (0-40PSI), 19-liter (5-gallon) reservoir typical
Stimulus Nozzles: Six per Mouse Lane, Ø 1.4mm x 13.9mm (Ø 0.055in x 0.545in)
Stimulus Duration: 200mS
Stimulus Repetition Rate: 1, 2, or 3Hz
Stimulus Control: 2-position toggle switch (on/off) for each lane
The INTENSITY adjusts the relative sensitivity of the capacitive touch
sensors
1.1.3 Optional Downhill Running Adapter
Adapter Dimensions: 25.4 x 49.5 x 27.7cm (10.0 x 19.5 x 10.9in)
Adapter Weight: 1.0kg (2.3lbs)
Adapter Effect: adds +30cm (+11.8in) to the overall height
Angle of Declination: 0°– 15° below the horizontal in 5° steps
1.1.4 Treadmill Controller
Power Requirements: 200 watts, 100, 115, or 230VAC, 50/60Hz (factory selected)
Physical Dimensions: 36.8 x 30.5 x 10.9cm (14.5 x 12.0 x 4.3in)
Physical Weight: 4.8kg (10.6lb)
User Controls: 3 x Push-Button Rotary Encoders
Speed Sensor Connection: 6.35mm (1/4in) Female Stereo Phone Jack
Fan Connections: 3.50mm (1/8in) Female Mono Phone Jack (x4)
CI-Bus Connections: 8p8c (RJ45 Ethernet) Modular Jack (x2)
Shocker Connection: 15-pin Female D-SUB
Motor Connection: 6-position Molex 5566 Mini-Fit Jr Male Header
Belt Speed Range: 0.0 – 102.3 meters/minute
Acceleration Range: 0.0 – 25.5 meters/minute/second
Time Limited Range: 0:00:01s to 4:15:59s
Distance Limited Range: 1.0 to 9,999.0 meters
1.1.5 Optional Calibration Wand
Power Requirements: 5VDC @ 100mA
Physical Dimensions: 20.3 x 4.6 x 4.3cm (8.0 x 1.8 x 1.7in)
Physical Weight: 0.2kg (0.5lb)
Connector: 6.35mm (1/4in) Stereo Phone Plug
Wheel Diameter: 4.128cm (1.625in)
Output: 100 pulses per revolution (771 pulses/meter)
1.1.6 CI-Bus Switch Mini
Power Requirements: 5VDC @ 500mA
Physical Dimensions: 6.63 x 6.6 x 2.7cm (2.6 x 2.3 x 1.1in)
Physical Weight: 0.06kg (0.137lb)
Computer Connection: USB 2.0 Type “B” Jack
