SYMBOLOGY USED ON THE MACHINE
Symbol denoting brake
It is used on top of the emergency and parking brake lever
Symbol denoting brake
It is used to indicate the signal lamp of the hand brake
Indication of the maximum temperature of the solution detergent
Placed near the charging hole of the solution tank
Symbol denoting the coupling
Indicates the anchor points and the load direction
Symbol recycling
Indicates the actuation control of the solution recycling system (optional)
Symbol denoting the open book
Indicates that, the operator has to read the manual before the use of the machine
