MACHINE PREPARATION
1. HANDLING OF THE PACKED MACHINE
The machine is packed in a specific package provided on a pallet for the handling with
fork trucks. The packages cannot be placed on top of each other.
The total weight is 277 kg for OMNIA26, 312 kg for OMNIA32 and 362 kg for OMNIA42.
The overall dimensions are:
A: 1260 mm
B: 1000 mm
C: 1740 mm
2. HOW TO UNPACK THE MACHINE
1.
Take off the outer package
2.
The machine is fixed on the pallet with metallic brackets
3.
Take off these brackets and possible wedges which block the wheels
Note Remember to reset the fastenings removed to take off the brackets
4. Using a chute, get the machine down from the pallet, pushing it in reverse motion.
Avoid violent blows to the base
5.
Keep the pallet and the fixing brackets for eventual transport necessities
3. CABLE CONNECTION TRACTION MOTOR
A technician of the Comac service dept. must carry out this operation.
