SYMBOLS USED ON THE MACHINE
Tap symbol
Used to indicate water regulation changes (CDS versions)
Detergent symbol
Used to indicate detergent regulation changes (CDS versions)
Indicator showing battery charge level on the upper line and hour-counter on the lower line
Indicator showing the type of hour-counter (total) on the upper line and the type of service (none) on the lower line
Indicator showing the type of technology of the batteries used (lead)
Main switch symbol (key switch)
Used on the instrument panel, to indicate the key switch for machine operation on (I) or off (O)
Indicates the maximum gradient
Battery symbol
Indicates the maximum temperature of the detergent solution
Located near the solution tank inlet
Symbol denoting brake
Located above the emergency and parking brake lever
