9
MACHINE PREPARATION
1. HANDLING THE PACKED MACHINE
The machine is contained in specific packaging.
It is not possible to place more than two packages on top of each other.
The overall dimensions of the package are:
SIMPLA 50BST-65BT SIMPLA 65BT
A 1077 1152
B 654 764
C 1424 1684
C
B
2. HOW TO UNPACK THE MACHINE
1. Remove the outer packaging.
2. Release the parking brake by removing the blocking pin (1).
3. The machine is fixed to the pallet with wedges which block the wheels.
4. Remove these wedges.
5. Use a chute to get the machine down from the pallet, pushing it backwards. Do not assemble the
rear squeegee before unloading the machine, and avoid violently jolting the brush base. To
assemble the squeegee, read the “ASSEMBLING THE SQUEEGEE” paragraph.
6. Keep the pallet for any future transport needs.
ATTENTION: if the product is delivered in cardboard containers, handle the
packed product with suitable lifting means that comply with the legal requirements.
3. HOW TO MOVE THE MACHINE
1. To safely transport the machine, the pallet should be used to support the machine, using a chute to
position the machine on the pallet and secure the wheels using the wooden wedges, as shown in
the previous paragraph.
2. Lower the squeegee (1) by means of the lever or the key (AU version).
3. Use the lever or key (AU version) to lower the base (2) until the brushes are resting on the floor.
4. Pull the brake lever (3) and block the machine using the pin (4).
