COMAC VISPA 35B - Technical Specifications; Machine Performance Data

5
TECHNICAL DESCRIPTION UM
Vispa 35B
Rated power W
500
Working width mm
350
Width of rear squeegee mm
440
Work capacity m
2
/h
1050
Water consumption g/m
2
-
Brushes (diameter or length) ∅ mm
350
Brush rotations rpm
140
Pressure on the brushes kg
20
Brush motor V / W
12 / 250
Type of advance
semi-aut.
Maximum gradient
2%
Suction motor V / W
12 / 250
Suction vacuum mbar
-
Solution tank PE l
10
Recovery tank PE l
10
Total machine weight (including batteries) kg
67
Gross weight of the machine ready for use kg
77
Battery V/Ah
12 / 65
Battery charger V/A
12/6
Battery compartment dimensions (Length / Height / Width) mm / mm / mm
277 / 224 / 172
Machine dimensions (Length / Height / Width) mm / mm / mm
682 / 1018 / 440
Length of the closed machine (without recovery tank) mm
795
Height of the closed machine (without recovery tank) mm
440
Noise level (in compliance with IEC 704/1) dB (A)
69.28
Vibration level m/s
2
1.79
