IS-NT-Async-SPI, SW Version 1.2, ©ComAp – February 2011
IS-NT-Async-SPI-1.2.PDF
77
SpeedGovLowLim [ V ]
Low limit for voltage on analog output of Speed Regulator.
Step: 0,01 V
Range: -10,00 V – SpeedGovHiLim
SpeedGovHiLim [ V ]
High limit for voltage on analog output of Speed Regulator.
Step: 0,01 V
Range: SpeedGovLowLim - 10,00 V
TauSpeedActuat [ s ]
Time constant of the speed actuator connected to the binary Up/Down outputs. This is to match the reaction
of the controller’s regulator with the actual reaction time of the actuator.
Step: 0,1 s
Range: 1,0 - 300,0 s
Load ramp [ s ] (FV)
Increasing or decreasing load rate. In seconds / Nomin power.
Step: 1 s
Range: 0 – GCB open del s
Force value possibility: Yes
Load gain [ % ]
Gain of power control loop.
Step: 0,1 %
Range: 0 – 200,0 %
Load int [ % ]
Relative integration factor of power control loop.
Step: 1 %
Range: 0 – 100 %
Hint
:
Load gain and Load int setpoints are active only when gen-set operates in parallel to the mains, when GCB
and MCB are closed.
RampStartLevel [ % ]
Value of initial load, on which starts the load ramping according to Load ramp setting in % of niminal load.
Step: 1 %
Range: 0 – 100 %
Hint
:
In case of higher value of this setpoint and closing the GCB with no load on the mains/bus, an overswing
may occur.
GCB open level [ % ]
Power level for opening the GCB while soft unload is in progress. If this level isn’t reached, the GCB opens
after GCB open del time.
Step: % of Nomin power
Range: 0 to 100 %
