Lights when at least one other unit is active on the CAN bus.
Blinks when no unit is communicated on the CAN bus (during
communication speed detection).
I-LB+ unit can be mounted on DIN rail (35 mm).
5.3.11. I-CB Communication Bridge
I-CB (Communication bridge) is CAN bus interface between Controller and Engine Control Unit
(ECU) that has not standard J1939 communication (MTU, CAT etc.). Engine values (RPM, Oil
pressure and other) are received from ECU via CAN and corresponding sensors are not
needed on controller. Use ICBEdit software for I-CB configuration (included in installation
package).
I-CB unit can be mounted on DIN rail (35 mm).
5.3.12. I-RB16, I-RB16/231 relay board
Relay board contains 16 relays for binary (open collector) output separation. All relays are
placed in sockets.
Number relays: 16 in socket
Nominal voltage: 24 VDC
Voltage range: 16,8 – 36 VDC
Relay opens at: 10% of nominal voltage
Electric / mechanic cycles: 100 000 (when switching 16A) / 10 000 000
Operating temperature range: - 40°C to 70°C
Maximal load: 16A resistive load
4A inductive load
Contacts protection: varistor 14DK390
Relay-connector connection:
