10. Outputs refresh rates
There are the following refresh rates for binary and analog outputs.
Type
Refresh rate
Analog Output on a controller
100ms
Binary Output on a controller
100ms @ minimum puls length 20ms
On demand if there is a „fast“ protection configured on
this output
Analog Output on an external
module
80ms times available modules for configuration (i.e. 4
modules available in standard FW results in 320ms
period)
Binary Output on an external
module
On demand when there is a change in binary state
with period 100ms times available modules for
configuration if there are no changes in binary states
(i.e. 12 modules available in standard FW results in
1200ms if there are no changes)
Speed Governor Output
Once per voltage period (20ms@50Hz)
AVRi
Once per voltage period (20ms@50Hz)
