InteliLite Global Guide
307
Setpoint group Scheduler Related FW 1.9.0
Range [units] [-]
Default value [-] Alternative config NO
Step [-]
Comm object 0 Related applications AMF, MRS
Config level Standard
Setpoint visibility Conditioned by the setpoint Timer 1 Function (page 303)
Description
Refresh period of Timer 1 Function (page 303). Meaning of this setpoint depends on type of repetition
adjusted in Timer 1 Repeated (page 306).
Daily
Range [units]: 1 .. 1000 [day]. This setpoint adjust that every X day the timer will
be activated.
Example: If you have daily repetition and you set this setpoint to 2, then
every second day from first occurrence of Timer 1 Function (page 303), the
Timer 1 Function (page 303) will be activated.
Weekly
Range [units]: 1 .. 60 [week]. This setpoint adjust that every X week the timer
will be activated.
Example: If you have weekly repetition and you set this setpoint to 2, then
every second week from first occurrence of Timer 1 Function (page 303),
the Timer 1 Function (page 303) will be activated in selected days adjusted
by Timer 1 Day (page 308).
Monthly
Range [units]: 1 .. 12 [month]. This setpoint adjust that every X month the timer
will be activated.
Example: If you have monthly repetition and you set this setpoint to 2, then
every second month from first occurrence of Timer 1 Function (page 303),
the Timer 1 Function (page 303) will be activated in selected day of month
adjusted by Timer 1 Repeat Day In Month (page 309) or in selected days
of week of month adjusted by Timer 1 Day (page 308) and Timer 1 Repeat
Week In Month (page 310).
Short Period
Range [units]: [HH:MM]. This setpoint adjust that every X short period the timer
will be activated.
Example: If you have short period repetition and you set this setpoint to 2,
then every second minute from first occurrence of Timer 1 Function (page
303), the Timer 1 Function (page 303) will be activated.
Timer 1 Refresh Period
6 back to List of setpoints
