InteliLite Global Guide
333
Setpoint group Basic settings Related FW 1.9.0
Range [units] 1 .. 5 000 [kW]
Default value 200 kW Alternative config Yes
Step 1 kW
Comm object 12046 Related applications AMF, MRS,
Config level Standard
Setpoint visibility Always
Description
Nominal power of the gen-set. Generator Overload BOC (page 227) protection is based on this setpoint.
Note: This setpoint is used when setpoint Connection type (page 177) is adjusted to Monophase or
Splitphase or 3Ph3Wire or High Leg D or 3Ph4Wire or when Autodetect detects connection type as
3Ph3Wire or High Leg D or 3Ph4Wire.
Note: This value is used when any other alternate configuration is not active.
Nominal Power 1
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units] 1 .. 5 000 [kW]
Default value 200 kW Alternative config Yes
Step 1 kW
Comm object 15771 Related applications AMF, MRS,
Config level Standard
Setpoint visibility Conditioned by the setpoint Connection type (page 177)
Description
Nominal power of the gen-set for detected split-phase or mono phase connection. Generator Overload BOC
(page 227) protection is based on this setpoint.
Note: This setpoint is used when setpoint Connection type (page 177) is adjusted to Autodetect and
Autodetect detects connection type as Monophase or Splitphase.
Note: This value is used when any other alternate configuration is not active.
Nominal Power Split Phase 1
6 back to List of setpoints
Setpoint group Basic settings Related FW 1.9.0
Range [units]
Mono Phase / SplPhL1L2 / SplPhL1L3 / 3Ph3Wire / 3Ph4Wire / High Leg D /
Autodetect [-]
Default value 3Ph4Wire Alternative config YES
Step [-]
Comm object 12059 Related applications AMF, MRS
Config level Standard
Connection type 2
