InteliLite Global Guide
698
Image 9.21 Main screen of CM-GPRS module
Image 9.22 Screen of AirGate
GSM Diag Code – Diagnostic code for CM-GPRS modem
Code Description
0 OK. No error.
1 Not possible to hang up.
2 Modul is switched off
3 Module is switched on
4 Module – error in initialization
5 Module – not possible to set the APN
6 Module – not possible to connect to GPRS network
7 Module – not possible to retrieve IP address
8 Module – not accepted DNS IP address
9 Error in modem detection
10 Error in initialization of analog modem
11
SIM card is locked (Possibly PIN code required, PIN needs to be deactivated) or unknown
status of SIM locking
12 No GSM signal
13 Not possible to read the SIM card parameters
GSM Diag Code – Common list of diagnostic codes for cellular modules
